Round cylinder, double-acting, Ø 32 mm, stroke 350 mm DSNU-32-350-P-A - Festo 559898

The Festo round cylinder DSNU-32-350-P-A is double-acting with a piston Ø of 32 mm and 350 mm stroke and pushes with 482.5 N at 6 bar. Elastic cushioning rings at both ends absorb the piston in the end positions.

Benefits

• Theoretical force at 6 bar: 482.5 N advance, 415 N return
• Piston Ø 32 mm and stroke 350 mm, defined by the order code DSNU-32-350-P-A
• Elastic cushioning rings at both ends (P)
• Cylinder barrel in high-alloy stainless steel
• Prepared for proximity switches to sense the end positions (code A in the type)
• Air connection G1/8, piston rod thread M10x1.25

Applications

The DSNU-32-350-P-A suits stopping, sorting and feeding tasks where 350 mm stroke and a piston Ø of 32 mm are sufficient. For load coupling the piston rod carries the thread M10x1.25, matching accessories for piston Ø 32 mm. For replacement please compare the type DSNU-32-350-P-A with the installed cylinder.
