Round cylinder, double-acting, Ø 32 mm, stroke 275 mm DSNU-32-275-PPV-A - Festo 594932

With its compact round design the DSNU-32-275-PPV-A delivers 275 mm of stroke and reaches 482.5 N on advance at 6 bar with a piston Ø of 32 mm and 415 N on return. The barrel of the DSNU-32-275-PPV-A is made of high-alloy stainless steel (CRC 2).

Benefits

• Piston Ø 32 mm and stroke 275 mm, defined by the order code DSNU-32-275-PPV-A
• Theoretical force at 6 bar: 482.5 N advance, 415 N return
• Pneumatic end-position cushioning PPV, adjustable at both ends, cushioning length 14 mm
• Cylinder barrel in high-alloy stainless steel
• Operating pressure 1 to 10 bar
• Prepared for proximity switches to sense the end positions (code A in the type)

Applications

With 275 mm stroke the DSNU-32-275-PPV-A handles pushing, lifting, clamping and ejecting tasks in assembly, packaging and handling. It is mounted with separate accessories. The M10x1.25 piston rod thread on the DSNU-32-275-PPV-A takes the matching rod-end accessories. For replacement please compare the type DSNU-32-275-PPV-A with the installed cylinder.
