Standards-based cylinder, double-acting, Ø 16 mm, stroke 400 mm DSNU-16-400-PPV-A - Festo 610157

With its compact round design the DSNU-16-400-PPV-A delivers 400 mm of stroke and reaches 120.6 N on advance at 6 bar with a piston Ø of 16 mm and 103.7 N on return. On the DSNU-16-400-PPV-A, barrel and piston rod are made of high-alloy stainless steel (CRC 2).

Benefits

• Piston Ø 16 mm and stroke 400 mm, defined by the order code DSNU-16-400-PPV-A
• Theoretical force at 6 bar: 120.6 N advance, 103.7 N return
• Conforms to CETOP RP 52 P, ISO 6432, standard mounting accessories fit
• Pneumatic end-position cushioning PPV, adjustable at both ends, cushioning length 12 mm
• Cylinder barrel and piston rod in high-alloy stainless steel
• Prepared for proximity switches to sense the end positions (code A in the type)

Applications

With 400 mm stroke the DSNU-16-400-PPV-A handles pushing, lifting, clamping and ejecting tasks in assembly, packaging and handling. It is mounted with separate accessories. For load coupling the piston rod carries the thread M6, matching accessories for piston Ø 16 mm. For replacement please compare the type DSNU-16-400-PPV-A with the installed cylinder.
