Standards-based cylinder double-acting Ø 100 mm stroke 250 mm DSBG-100-250-PPVA-N3-243V - Festo 604930
DSBG series standards-based cylinder for machine building: DSBG-100-250-PPVA-N3-243V with a 100 mm piston and 250 mm stroke. Comes with adjustable pneumatic end-position cushioning (PPV) and position sensing via proximity switch.
Net
excl. VAT
€567.19
Item
FES-604930
Manufacturer no.
DSBG-100-250-PPVA-N3-243V
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo DSBG-100-250-PPVA-N3-243V is a double-acting standards-based cylinder with a 100 mm piston and 250 mm stroke and adjustable pneumatic end-position cushioning (PPV). The data below is taken from the Festo type code DSBG-100-250-PPVA-N3-243V, further values are given in the Festo data sheet.
Benefits
- Soft into the end position: adjustable pneumatic cushioning (PPV) at both ends
- Position sensing: prepared for proximity switches
Applications
Typical tasks are lifting, pushing, clamping and pressing in fixtures, handling and special machinery.
Technical data
| Piston diameter | 100 mm |
|---|---|
| Stroke | 250 mm |
| Mode of operation | double-acting |
| Cushioning | PPV: pneumatic cushioning, adjustable at both ends |
| Position detection | via proximity switch |
| Mounting position | any |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | lubricated operation possible (then required for all further operation) |
| Weight (price list) | 8 kg |
| Type | DSBG-100-250-PPVA-N3-243V |
| Festo part number | 604930 |
| Weight | 8 kg |
| Manufacturer | Festo |
| Hersteller-Nr | DSBG-100-250-PPVA-N3-243V |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 100 |
| Stroke [mm] | 250 |
| Medium | Compressed air |
| Function | double-acting |
| Series | DSBG |
| Bore (mm) | 100 |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
