Normzylinder DSBC-40-25-E2D3-PPVA - Festo 595341

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Double-acting standard cylinder Ø 40 mm stroke 25 mm DSBC-40-25-E2D3-PPVA - Festo 595341

Name: Double-acting standard cylinder Ø 40 mm stroke 25 mm DSBC-40-25-E2D3-PPVA - Festo 595341
Brand: Festo
SKU: FES-595341
Price: 402.81 EUR
Availability: InStock

Festo ✓ Original product Brand new

25 mm stroke with a Ø 40 mm piston: these are the key data of the double-acting Festo standard cylinder DSBC-40-25-E2D3-PPVA. The code PPVA in the type stands for pneumatic cushioning adjustable at both ends and sensing via proximity switches. The cylinder weighs 0.95 kg.

Net

€402.81

excl. VAT

Item FES-595341

Manufacturer no. DSBC-40-25-E2D3-PPVA

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

With a 25 mm stroke and a Ø 40 mm piston, the Festo standard cylinder DSBC-40-25-E2D3-PPVA covers positioning and feed tasks. Being double-acting, the Ø 40 mm piston is driven by compressed air in both directions.

Key benefits

Piston Ø 40 mm, stroke 25 mm
Adjustable end-position cushioning PPV
End positions can be sensed with proximity switches
Double-acting: force in both directions
Weight 0.95 kg
Clearly identified by Festo part number 595341

Typical applications

Typical tasks for the DSBC-40-25-E2D3-PPVA are clamping, ejecting and shifting over 25 mm in assembly and test systems.

Technical data

Order type	DSBC-40-25-E2D3-PPVA
Festo part number	595341
Piston diameter	40 mm
Stroke	25 mm
Mode of operation	double-acting
Cushioning	PPV: pneumatic cushioning, adjustable at both ends
Position detection	via proximity switch
Weight	0.95 kg
Customs tariff number	84123100
Manufacturer	Festo
Hersteller-Nr	DSBC-40-25-E2D3-PPVA
Zolltarifnummer	84123100
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
Piston Ø [mm]	40
Stroke [mm]	25
Function	double-acting
Series	DSBC
Bore (mm)	40
