Pressure switch, G 1/4", 10 - 80 bar, zinc die casting / aluminium pulverbeschichtet

On pumps, compressors and hydraulic power units the pressure switch takes over pressure monitoring. The setting range extends over 10 - 80 bar. The body is made of zinc die casting / aluminium pulverbeschichtet. The device is screwed in with G 1/4". The overpressure safety amounts to 350 bar.

Benefits

• Temperature range -20 to +80 °C for use in the workshop and in the plant
• Degree of protection IP 65 against dust and moisture at the installation point
• Version according to DIN 43650
• Setting range 10 - 80 bar as the leading rating of the device
• Connection thread G 1/4" for direct installation in the line
• Overpressure safety 350 bar, so the load limit is clearly stated

Applications

Machine construction with electrical control, maintenance, retrofitting of measuring points.

Standards and conformity

The data sheets refer to DIN 43650, EN 175301-803. Further approvals are not documented and are therefore not stated.
