Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
Reports to the control system when the set pressure is reached. The device is screwed in with G 1/4". The setting range extends over 1 - 10 bar.
Pressure switch, G 1/4", 1 - 10 bar, zinc plated steel, overpressure safety 300 bar, 42 V / 100 VA
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€30.91
Item
FL-003129
Manufacturer no.
DRSO 10
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.DRSO 10
EAN4050571273071
Customs tariff number90268080
ConditionNew
Artikel
FL-003129
Frequently Bought Together
-
This Item:
€30.91
-
Safety relief valve G 1-1/2", factory set and sealed, DN 31, 27 bar, brass
€311.18
-
Accessory for compressed air equipment, G 3/8", 0 - 16 bar, PA 66 GF60, metal bowl with sight glass
€106.30
Total price
Where a control system has to react to pressure, this pressure switch supplies the matching contact. The setting range extends over 1 - 10 bar. The body is made of zinc plated steel. The device is screwed in with G 1/4". The overpressure safety amounts to 300 bar.
Benefits
- Temperature range -30 to +100 °C for use in the workshop and in the plant
- Degree of protection IP 65 against dust and moisture at the installation point
- Switching capacity 42 V / 100 VA at the output contact
- Setting range 1 - 10 bar as the leading rating of the device
- Connection thread G 1/4" for direct installation in the line
- Overpressure safety 300 bar, so the load limit is clearly stated
Technical data
| Property | Value |
|---|---|
| Version | pressure switch |
| Switch type | normally closed contact |
| Setting range [bar] | 1 - 10 |
| Thread | G 1/4" (male) |
| Material | zinc plated steel |
| Overpressure safe up to [bar] | 300 |
| Switching capacity | 42 V / 100 VA |
| Operating voltage | 0 - 42 V (AC/DC) |
| Electrical connection | screw terminals |
| Protective cap | available as an accessory |
| Temperature range [°C] | -30 to +100 |
| Media | hydraulic oil, machine oil, fuel oil, air, (to a limited extent also for water suitable) |
| Degree of protection | IP 65 |
Applications
Compressor controls, pump monitoring, hydraulic power units and limit signalling in machines.
| Weight | 0.075000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | DRSO 10 |
| EAN | 4050571273071 |
| Zolltarifnummer | 90268080 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Druckschalter |
| Material | Galvanised steel |
| Thread | G 1/4 AG |
| Operating voltage | 0 - 42 V (AC/DC) |
| Temperaturbereich | -30-100 °C |
