Flow control valve with check function, exhaust air control, M 5, tube 6 mm, -0.95 to 1 bar

The speed of a pneumatic cylinder is set through the air volume, not through the pressure. This flow control valve with check function connects the thread M 5 to a tube of 6 mm outside diameter and works with exhaust air control. The throttle screw acts in one flow direction only, in the opposite direction the check valve opens fully. The materials are body Nickel-plated brass / PBT, seal NBR, retaining claw stainless steel, cartridge ZnDC nickel-plated, release ring PBT. The temperature range runs from 0 to +60 °C.

Advantages

• Media Compressed air, neutral gases, the valve needs no separate treatment.
• Version exhaust air control, so the speed is limited on the correct side of the piston.
• Push-in connector for tube with 6 mm outside diameter, release works without tools through the release ring.
• Connection thread M 5 for screwing directly into the cylinder end cap.
• Materials body Nickel-plated brass / PBT, seal NBR, retaining claw stainless steel, cartridge ZnDC nickel-plated, release ring PBT, only silicone-free seals and lubricants are used during assembly.

Technical data

Applications

• Avoiding the stick-slip effect on slow running actuators.
• Matching forward and return stroke in cycled handling devices.
• Production environments within the temperature range 0 to +60 °C.
• Speed adjustment on pneumatic cylinders with 6 mm tube.
