Doppelkolbenzylinder DPZJ-25-80-P-A-S2-SA - Festo 1907504

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Twin-piston cylinder with yoke Ø 25 mm 80 mm stroke DPZJ-25-80-P-A-S2-SA - Festo 1907504

Name: Twin-piston cylinder with yoke Ø 25 mm 80 mm stroke DPZJ-25-80-P-A-S2-SA - Festo 1907504
Brand: Festo
SKU: FES-1907504
Price: 672.51 EUR
Availability: InStock

Festo ✓ Original product Brand new

The DPZJ-25-80-P-A-S2-SA twin-piston cylinder with yoke puts two pistons on one guided unit, 25 mm piston diameter and 80 mm stroke. Elastic cushioning rings absorb the end positions at both ends. The piston rod runs through on both sides.

Net

€672.51

excl. VAT

Item FES-1907504

Manufacturer no. DPZJ-25-80-P-A-S2-SA

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Festo DPZJ-25-80-P-A-S2-SA twin-piston cylinder has a 25 mm piston and 80 mm stroke.

Benefits

Cushioning: elastic cushioning rings at both ends
Through piston rod: attachments possible on both sides
Position detection: prepared for proximity switches

Applications

The DPZJ-25-80-P-A-S2-SA handles guided lifting and pushing motions in automation and handling systems. Please confirm force, port size and operating pressure of the DPZJ-25-80-P-A-S2-SA in the Festo data sheet before sizing.

Technical data

Type	DPZJ-25-80-P-A-S2-SA
Festo part number	1907504
Piston diameter	25 mm
Stroke	80 mm
Cushioning	P: Elastic cushioning rings/plates at both ends
Position detection	Via proximity switch
Variants	Through piston rod
Weight	1.7 kg
Manufacturer	Festo
Hersteller-Nr	DPZJ-25-80-P-A-S2-SA
Zolltarifnummer	84123100
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
Piston Ø [mm]	25
Stroke [mm]	80
Series	DPZJ
Bore (mm)	25
