Direct solenoid actuated poppet valve, G1/4, 3/2, NC - Norgren 2401086200400000
The solenoid is replaced without tools. The direct solenoid actuated poppet valve Norgren 2401086200400000 seals with nitrile rubber (nbr) and runs on an operating voltage of 17 to 28 V DC.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated poppet valve Norgren 2401086200400000 has a Kv value of 0.34 m³/h and reaches a flow of 375 l/min.
Benefits
- Main application is single acting actuators in intrinsically safe circuits
- Solenoid valve with low power consumption
- Suited to outdoor use under critical environmental conditions
- Port size G1/4
- Operating pressure 0 to 10 bar
- Flow 375 l/min
Applications
The valve is used in water treatment, cleaning and dosing plants and in gas lines.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The product conforms to SIL3. The housing reaches protection class IP66 with cable gland (included). For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 2,500,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 2401086200400000 |
| Series | 24010 |
| Standard | SIL3 |
| Valve function | 3/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Poppet |
| Port size | G1/4 |
| Nominal diameter | 5 mm |
| Operating pressure | 0 to 10 bar |
| Flow | 375 l/min |
| Kv value | 0.34 m³/h |
| Cv flow coefficient | 0.39 gpm |
| Medium | Compressed air |
| Fluid temperature | -25 to 80 °C |
| Ambient temperature | -25 to 80 °C |
| Body material | Stainless steel |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | M20 x 1.5 |
| Operating voltage | 17 to 28 V DC |
| Power consumption | 1.5 W |
| Coil code | 2004 |
| Protection class | IP66 with cable gland (included) |
| b10 value | 2,500,000 cycles |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 2401086200400000 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Certification | DIN EN ISO 13849 |
