Direct solenoid actuated piston valve with forced lifitng, G1/2, 2/2, NC - Norgren 8672201.8406.23049

Process valves switch water, gases and other media in process plants. The direct solenoid actuated piston valve with forced lifitng Norgren 8672201.8406.23049 is released for fluid temperatures of 0 to 200 °C and has a Kv value of 4.4 m³/h.

Benefits

• The valve operates without differential pressure
• High flow rate
• Suitable for vacuum
• Port size G1/2
• Operating pressure 0 to 16 bar
• Body made of Brass

Applications

The valve is used in water treatment, cleaning and dosing plants and in gas lines.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65.
