Direct solenoid actuated piston valve with forced lifitng, G1-1/2, 2/2, NC - Norgren 8672600.8406.02449
The solenoid is replaced without tools. The direct solenoid actuated piston valve with forced lifitng Norgren 8672600.8406.02449 has a Kv value of 23 m³/h and covers the temperature range 0 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated piston valve with forced lifitng Norgren 8672600.8406.02449 runs on an operating voltage of 24 V AC and seals with polytetrafluoroethylene (ptfe).
Benefits
- The valve operates without differential pressure
- High flow rate
- Suitable for vacuum
- Port size G1-1/2
- Operating pressure 0 to 16 bar
- Body made of Brass
Applications
The valve is used in water treatment, cleaning and dosing plants and in gas lines.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8672600.8406.02449 |
| Series | 86720 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Piston valve |
| Port size | G1-1/2 |
| Nominal diameter | 40 mm |
| Operating pressure | 0 to 16 bar |
| Kv value | 23 m³/h |
| Cv flow coefficient | 26.6 gpm |
| Medium | Gases, Liquids |
| Fluid temperature | 0 to 200 °C |
| Ambient temperature | 0 to 60 °C |
| Body material | Brass |
| Seal material | Polytetrafluoroethylene (PTFE) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V AC |
| Power consumption | 33 VA |
| Coil code | 8406 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8672600.8406.02449 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
