Direct solenoid actuated piston valve with forced lifitng, 15 mm flange, 2/2, NC - Norgren 8650200.8301.02400
The solenoid is replaced without tools. The direct solenoid actuated piston valve with forced lifitng Norgren 8650200.8301.02400 has a body made of cast steel and covers the temperature range -20 to 50 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated piston valve with forced lifitng Norgren 8650200.8301.02400 is suitable for gases, liquids and runs on an operating voltage of 24 V DC.
Benefits
- Operating pressure 0 to 25 bar
- Body made of Cast steel
- Seal material Nitrile rubber (NBR)
- Operating voltage 24 V DC
- Protection class IP65
Applications
Typical installations are cooling circuits, washing and filling plants and filter systems.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8650200.8301.02400 |
| Series | 86500 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Piston valve |
| Nominal diameter | 15 mm |
| Operating pressure | 0 to 25 bar |
| Kv value | 4.4 m³/h |
| Cv flow coefficient | 5.1 gpm |
| Medium | Gases, Liquids |
| Fluid temperature | -20 to 90 °C |
| Ambient temperature | -20 to 50 °C |
| Body material | Cast steel |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V DC |
| Power consumption | 22 W |
| Coil code | 8301 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8650200.8301.02400 |
| Zolltarifnummer | 84818073 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
