Force-lifted 2/2-way diaphragm valve NC, G3/8, DN 10, 230 V AC, NBR - Norgren 8253150.8001.23050
The Norgren force-lifted diaphragm valve 8253150.8001.23050 switches gases and liquids at port G3/8 across 0 to 10 bar without differential pressure and reaches a Kv value of 1.7 m³/h. For the 8253150.8001.23050: coil 8001 with 230 V AC and NBR seals for media from -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8253150.8001.23050 is designed for gases and liquids across 0 to 10 bar with port G3/8 and nominal diameter 10 mm. Because the armature lifts the diaphragm positively, the 8253150.8001.23050 switches from 0 bar without differential pressure.
Operating benefits
- Switches without differential pressure across 0 to 10 bar
- Vacuum-rated down to -0.9 bar
- Kv value 1.7 m³/h (Cv 1.97 gpm) at nominal diameter 10 mm
- Compact solenoid system with integrated core tube
- Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Solenoid coil 8001 for 230 V AC, power consumption 20/16 VA
Applications
The 8253150.8001.23050 with port G3/8 is used for washing and filling systems, gas lines and cooling circuits whenever gases and liquids have to be switched across 0 to 10 bar.
Standards and conformity
Documented for the Norgren 8253150.8001.23050: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8253150.8001.23050 contains no SVHC substances and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8253150.8001.23050 |
| Series | 82530 |
| Design | Force-lifted diaphragm valve |
| Valve function | 2/2 NC (normally closed) |
| Actuation | Solenoid pilot, spring return |
| Port size | G3/8 |
| Nominal diameter | 10 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 1.7 m³/h |
| Cv value | 1.97 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 20/16 VA |
| Coil code | 8001 |
| Protection class | IP65 |
| Vacuum | down to -0.9 bar |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8253150.8001.23050 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 3/8 |
| Nominal size DN [mm] | 10 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
