Force-lifted 2/2-way diaphragm valve NC, G3/4, DN 20, 110 V AC, NBR - Norgren 8254300.9304.11049
The Norgren force-lifted diaphragm valve 8254300.9304.11049 switches gases and liquids at port G3/4 across 0 to 16 bar without differential pressure and reaches a Kv value of 5.8 m³/h. At port G3/4 the coil 9304 runs on 110 V AC, and NBR seals are rated for -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a Kv value of 5.8 m³/h and a nominal diameter of 20 mm the Norgren force-lifted diaphragm valve 8254300.9304.11049 controls lines with port G3/4, normally closed. Because the armature lifts the diaphragm positively, the 8254300.9304.11049 switches from 0 bar without differential pressure.
Operating benefits
- Switches without differential pressure across 0 to 16 bar, suited to low or fluctuating pressure
- Vacuum-rated down to -0.9 bar
- Kv value 5.8 m³/h (Cv 6.7 gpm) at nominal diameter 20 mm
- Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Solenoid coil 9304 for 110 V AC, power consumption 20 VA
Applications
Typical locations for the valve 8254300.9304.11049 are water treatment, cleaning and dosing systems and machine building where gases and liquids at temperatures of -10 to 90 °C have to be switched.
Standards and conformity
Documented for the Norgren 8254300.9304.11049: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254300.9304.11049 contains an SVHC substance and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8254300.9304.11049 |
| Series | 82540 |
| Design | Force-lifted diaphragm valve |
| Valve function | 2/2 NC (normally closed) |
| Actuation | Solenoid pilot, spring return |
| Port size | G3/4 |
| Nominal diameter | 20 mm |
| Operating pressure | 0 to 16 bar |
| Kv value | 5.8 m³/h |
| Cv value | 6.7 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 110 V AC |
| Power consumption | 20 VA |
| Coil code | 9304 |
| Protection class | IP65 |
| Vacuum | down to -0.9 bar |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains an SVHC substance |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8254300.9304.11049 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 3/4 |
| Nominal size DN [mm] | 20 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
