Force-lifted 2/2-way diaphragm valve NC, G3/4, DN 20, 230 V AC, NBR - Norgren 8254300.9154.23049

Norgren ✓ Original product Brand new

The Norgren force-lifted diaphragm valve 8254300.9154.23049 switches gases and liquids at port G3/4 across 0 to 10 bar without differential pressure and reaches a Kv value of 5.8 m³/h. At port G3/4 the coil 9154 runs on 230 V AC, and NBR seals are rated for -10 to 90 °C.

Net
€283.99
excl. VAT
Item NRG-8254300.9154.23049
Manufacturer no. 8254300.9154.23049
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With a Kv value of 5.8 m³/h and a nominal diameter of 20 mm the Norgren force-lifted diaphragm valve 8254300.9154.23049 controls lines with port G3/4, normally closed. Because the armature lifts the diaphragm positively, the 8254300.9154.23049 switches from 0 bar without differential pressure.

Operating benefits

  • Switches without differential pressure across 0 to 10 bar, suited to low or fluctuating pressure
  • Vacuum-rated down to -0.9 bar
  • Kv value 5.8 m³/h (Cv 6.7 gpm) at nominal diameter 20 mm
  • Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 9154 for 230 V AC, power consumption 20 VA

Applications

Typical locations for the valve 8254300.9154.23049 are water treatment, cleaning and dosing systems and machine building where gases and liquids at temperatures of -10 to 90 °C have to be switched.

Standards and conformity

Documented for the Norgren 8254300.9154.23049: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254300.9154.23049 contains an SVHC substance and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8254300.9154.23049
Series82540
DesignForce-lifted diaphragm valve
Valve function2/2 NC (normally closed)
ActuationSolenoid pilot, spring return
Port sizeG3/4
Nominal diameter20 mm
Operating pressure0 to 10 bar
Kv value5.8 m³/h
Cv value6.7 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage230 V AC
Power consumption20 VA
Coil code9154
Protection classIP65
Vacuumdown to -0.9 bar
Weight0.95 kg
Country of originGermany
RoHScompliant
REACHcontains an SVHC substance
WEEEsubject to WEEE
Hersteller-Nr8254300.9154.23049
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 3/4
Nominal size DN [mm]20
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803
Betriebsdruck max [bar]10
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
