Diaphragm valve with forced lifting, 2/2 NC, G2, DN 50, NBR, 24 V AC - Norgren 8254700.9404.02449

Norgren ✓ Original product Brand new

Switches gases and liquids from 0 bar without differential pressure up to 16 bar, the Norgren diaphragm valve 8254700.9404.02449 reaches a Kv value of 41 m³/h at port G2. The 8254700.9404.02449 is normally closed, its coil 9404 runs on 24 V AC at 42 VA with protection class IP65.

Net
€802.19
excl. VAT
Item NRG-8254700.9404.02449
Manufacturer no. 8254700.9404.02449
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren diaphragm valve 8254700.9404.02449 with forced lifting opens and closes port G2 at an operating pressure of 0 to 16 bar. At nominal diameter DN 50 the Kv value of the 8254700.9404.02449 is 41 m³/h, which also suits lines with low or fluctuating pressure.

Benefits

  • Kv value 41 m³/h or Cv value 47.4 gpm at port G2
  • Operates without differential pressure from 0 bar up to 16 bar
  • Seals made of nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Body made of brass for ambient temperatures of -10 to 50 °C
  • Coil 9404 with 24 V AC and 42 VA, connection to DIN EN 175301-803 form A

Applications

The diaphragm valve 8254700.9404.02449 shuts off and opens lines carrying gases and liquids, for example in cooling circuits, washing and filling systems or compressed air distribution, provided NBR is compatible with the medium.

Standards and conformity

The 8254700.9404.02449 is RoHS compliant and contains an SVHC substance under REACH. The coil connector of the 8254700.9404.02449 follows DIN EN 175301-803 form A.

Technical data

ManufacturerNorgren
Part number8254700.9404.02449
Product typediaphragm valve
Series82540
Valve function2/2
Switching functionNC (normally closed)
Designdiaphragm valve with forced lifting
Valve technologydiaphragm
Port sizeG2
Nominal diameterDN 50
Operating pressure0 to 16 bar
Kv value41 m³/h
Cv value47.4 gpm
Mediumgases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialbrass
Seal materialnitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage24 V AC
Power consumption42 VA
Coil code9404
Protection classIP65
Country of originGermany
RoHScompliant
REACHcontains SVHC substance
WEEEsubject to WEEE
Customs tariff number84812090
Hersteller-Nr8254700.9404.02449
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]50
Housing materialBrass
Function2/2
Actuation typeElectrical
NormDIN EN 175301-803
Betriebsdruck max [bar]16
Pneumatic connectionG2
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
