Solenoid actuated diaphragm valve with forced lifting, G1/4, 2/2 NC, stainless steel - Norgren 8259001.9150.00000
Switches reliably at a small pressure difference and needs no minimum differential pressure. Norgren 8259001.9150.00000 works in function 2/2 NC with a Kv value of .
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren 8259001.9150.00000 is a diaphragm valve with forced lifting in function 2/2 NC and switches gases and liquids at an operating pressure of 0 to 10 bar.
Benefits
- High flow rate
- Damped operation
- For systems with low or fluctuating pressure
- Operating pressure 0 to 10 bar in function 2/2 NC
- Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Protection class IP65 with connector at an ambient temperature of -10 to 50 °C
Applications
Typical installations are cooling circuits, washing and filling plants and gas lines with fluid temperatures of -10 to 90 °C.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with connector.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8259001.9150.00000 |
| Series | 82590 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G1/4 |
| Nominal diameter | 8 mm |
| Operating pressure | 0 to 10 bar |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Stainless steel |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | Without solenoid |
| Coil code | 9150 |
| Protection class | IP65 with connector |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8259001.9150.00000 |
| Zolltarifnummer | 84818073 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
