Solenoid actuated diaphragm valve with forced lifting, G1, 2/2 NC, 24 V AC - Norgren 8259400.9154.02449
Switches reliably at a small pressure difference and needs no minimum differential pressure. Norgren 8259400.9154.02449 works in function 2/2 NC with a Kv value of 8 m³/h.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The diaphragm valve with forced lifting Norgren 8259400.9154.02449 carries out function 2/2 NC with a Kv value of 8 m³/h.
Benefits
- High flow rate
- Damped operation
- For systems with low or fluctuating pressure
- Operating pressure 0 to 10 bar in function 2/2 NC
- Kv value 8 m³/h and Cv value 9.2 gpm
- Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
Applications
The valve is used in water treatment, in cleaning and dosing plants and in machine building wherever gases and liquids have to be switched at 0 to 10 bar.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. The housing reaches protection class IP65.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8259400.9154.02449 |
| Series | 82590 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G1 |
| Nominal diameter | 25 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 8 m³/h |
| Cv flow coefficient | 9.2 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Stainless steel |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V AC |
| Power consumption | 20 VA |
| Coil code | 9154 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8259400.9154.02449 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
