Force-lifted 2/2-way diaphragm valve NC, G1, DN 25, 110 V AC, NBR - Norgren 8254400.9154.11049
The Norgren force-lifted diaphragm valve 8254400.9154.11049 switches gases and liquids at port G1 across 0 to 10 bar without differential pressure and reaches a Kv value of 8 m³/h. At port G1 the coil 9154 runs on 110 V AC, and NBR seals are rated for -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8254400.9154.11049 is a normally closed force-lifted diaphragm valve of series 82540 for G1 lines with nominal diameter 25 mm. Because the armature lifts the diaphragm positively, the 8254400.9154.11049 switches from 0 bar without differential pressure.
Operating benefits
- Switches without differential pressure across 0 to 10 bar, suited to low or fluctuating pressure
- Vacuum-rated down to -0.9 bar
- Kv value 8 m³/h (Cv 9.2 gpm) at nominal diameter 25 mm
- Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Solenoid coil 9154 for 110 V AC, power consumption 20 VA
Applications
The Norgren 8254400.9154.11049 is installed in gas lines, cooling circuits and washing and filling systems where gases and liquids at 0 to 10 bar and ambient temperatures of -10 to 50 °C have to be controlled.
Standards and conformity
Documented for the Norgren 8254400.9154.11049: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254400.9154.11049 contains an SVHC substance and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8254400.9154.11049 |
| Series | 82540 |
| Design | Force-lifted diaphragm valve |
| Valve function | 2/2 NC (normally closed) |
| Actuation | Solenoid pilot, spring return |
| Port size | G1 |
| Nominal diameter | 25 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 8 m³/h |
| Cv value | 9.2 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 110 V AC |
| Power consumption | 20 VA |
| Coil code | 9154 |
| Protection class | IP65 |
| Vacuum | down to -0.9 bar |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains an SVHC substance |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8254400.9154.11049 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1 |
| Nominal size DN [mm] | 25 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
