Solenoid actuated diaphragm valve with forced lifting, G1/2, 2/2 NC, stainless steel - Norgren 8259200.9150.00000

The diaphragm valve with forced lifting Norgren 8259200.9150.00000 carries out function 2/2 NC with a Kv value of 3.4 m³/h.

Benefits

• High flow rate
• Damped operation
• For systems with low or fluctuating pressure
• Operating pressure 0 to 10 bar in function 2/2 NC
• Kv value 3.4 m³/h and Cv value 3.9 gpm
• Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C

Applications

The valve is used in water treatment, in cleaning and dosing plants and in machine building wherever gases and liquids have to be switched at 0 to 10 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with connector.
