Direct solenoid actuated diaphragm valve with forced lifting, G1/2, 2/2, NC - Norgren 8256200.8004.23049
Shuts off contaminated media reliably. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8256200.8004.23049 seals with nitrile rubber (nbr) and is manufactured in Germany.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8256200.8004.23049 covers the temperature range -10 to 50 °C and is manufactured in Germany.
Benefits
- Suitable for vacuum
- Compact solenoid with integrated core tube
- The valve operates without pressure differential
- Port size G1/2
- Operating pressure 0 to 10 bar
- Body made of Stainless steel
Applications
Typical installations are cooling circuits, washing and filling plants and filter systems.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8256200.8004.23049 |
| Series | 82560 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G1/2 |
| Nominal diameter | 10 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 1.7 m³/h |
| Cv flow coefficient | 1.97 gpm |
| Medium | Gases, Liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Stainless steel |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 13 VA |
| Coil code | 8004 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8256200.8004.23049 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
