Diaphragm solenoid valve 2/2 NC, G 1/2, DN 12, 230 V AC, 82540 series - Norgren 8254214.9304.23049

Norgren ✓ Original product Brand new

The Norgren 8254214.9304.23049 switches gases and liquids through G 1/2 ports with DN 12 nominal size across 0 to 16 bar. The 9304 coil of the 8254214.9304.23049 runs on 230 V AC at 20 VA, protection class IP65.

Net
€264.49
excl. VAT
Item NRG-8254214.9304.23049
Manufacturer no. 8254214.9304.23049
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With Kv 3.4 m³/h at DN 12 and G 1/2 ports, the Norgren 8254214.9304.23049 switches gases and liquids across 0 to 16 bar. The 8254214.9304.23049 uses coil 9304 for 230 V AC at 20 VA with protection class IP65. A brass body and EPDM seals define the media compatibility of the 8254214.9304.23049.

Benefits

  • Kv value 3.4 m³/h, Cv value 3.9 gpm at DN 12 nominal size
  • Operating pressure 0 to 16 bar for gases and liquids
  • Brass body, EPDM seals
  • Fluid temperature -10 to 90 °C, ambient temperature -10 to 50 °C
  • Coil 9304 for 230 V AC, 20 VA, protection class IP65

Applications

The 8254214.9304.23049 suits gases and liquids compatible with EPDM, at fluid temperatures of -10 to 90 °C. As the operating pressure starts at 0 bar, the 8254214.9304.23049 switches without a minimum pressure difference.

Standards and compliance

The 8254214.9304.23049 uses a DIN EN 175301-803 form A electrical connection. The 8254214.9304.23049 is RoHS compliant, contains an SVHC substance under REACH and is covered by the WEEE directive.

Technical data

Product typeDiaphragm solenoid valve
Series82540
Valve function2/2
FunctionNC (normally closed)
ActuationSolenoid pilot / spring return
Valve technologyDiaphragm
Port sizeG 1/2
Nominal diameter12 mm
Operating pressure0 to 16 bar
Kv value3.4 m³/h
Cv flow coefficient3.9 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialEthylene propylene diene monomer (EPDM)
Electrical connectionDIN EN 175301-803 form A
Operating voltage230 V AC
Power consumption20 VA
Coil code9304
Protection classIP65
Country of originGermany
RoHSCompliant
REACHSVHC substance present
WEEEWEEE
Manufacturer part number8254214.9304.23049
ManufacturerNorgren
Hersteller-Nr8254214.9304.23049
Zolltarifnummer84818079
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Nominal size DN [mm]12
Housing materialBrass
Designdiaphragm valve
Actuation typeElectrical
Medientemperatur [°C]-10 bis 90
NormDIN EN 175301-803
Betriebsdruck max [bar]16
Protection ratingIP65
