Diaphragm valve 2/2 NC, G 1/2, DN 12, without solenoid coil, 82540 series - Norgren 8254203.9150.00000
The Norgren 8254203.9150.00000 diaphragm valve is closed at rest and passes gases and liquids with Kv 3.4 m³/h through G 1/2 ports. The 8254203.9150.00000 is deliberately supplied without coil, leaving the control voltage open.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8254203.9150.00000 switches gases and liquids through G 1/2 ports with DN 12 nominal size across 0 to 10 bar. The 8254203.9150.00000 is shipped without solenoid coil, the coil is not part of the delivery. A brass body and FPM seals define the media compatibility of the 8254203.9150.00000.
Benefits
- Kv value 3.4 m³/h, Cv value 3.9 gpm at DN 12 nominal size
- Operating pressure 0 to 10 bar for gases and liquids
- Brass body, FPM seals
- Fluid temperature -10 to 90 °C, ambient temperature -10 to 50 °C
Applications
The 8254203.9150.00000 suits gases and liquids compatible with FPM, at fluid temperatures of -10 to 90 °C. As the operating pressure starts at 0 bar, the 8254203.9150.00000 switches without a minimum pressure difference.
Standards and compliance
The 8254203.9150.00000 is RoHS compliant, contains an SVHC substance under REACH and is covered by the WEEE directive.
Technical data
| Product type | Diaphragm valve |
|---|---|
| Series | 82540 |
| Valve function | 2/2 |
| Function | NC (normally closed) |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1/2 |
| Nominal diameter | 12 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 3.4 m³/h |
| Cv flow coefficient | 3.9 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Fluorocarbon rubber (FPM) |
| Electrical connection | without solenoid coil |
| Coil code | 9150 |
| Protection class | IP65 with connector |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Weight | 0.45 kg |
| Manufacturer part number | 8254203.9150.00000 |
| Manufacturer | Norgren |
| Hersteller-Nr | 8254203.9150.00000 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/2 |
| Nominal size DN [mm] | 12 |
| Housing material | Brass |
| Design | diaphragm valve |
| Medientemperatur [°C] | -10 bis 90 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
