Force-lifted 2/2-way diaphragm valve NC, G1/2, DN 12, 24 V AC, NBR - Norgren 8254200.9304.02449

Norgren ✓ Original product Brand new

The Norgren force-lifted diaphragm valve 8254200.9304.02449 switches gases and liquids at port G1/2 across 0 to 16 bar without differential pressure and reaches a Kv value of 3.4 m³/h. The solenoid coil 9304 for 24 V AC draws 20 VA, and NBR seals handle media from -10 to 90 °C.

Net
€236.38
excl. VAT
Item NRG-8254200.9304.02449
Manufacturer no. 8254200.9304.02449
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 8254200.9304.02449 is designed for gases and liquids across 0 to 16 bar with port G1/2 and nominal diameter 12 mm. Because the armature lifts the diaphragm positively, the 8254200.9304.02449 switches from 0 bar without differential pressure.

Operating benefits

  • Switches without differential pressure across 0 to 16 bar, suited to low or fluctuating pressure
  • Vacuum-rated down to -0.9 bar
  • Kv value 3.4 m³/h (Cv 3.9 gpm) at nominal diameter 12 mm
  • Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 9304 for 24 V AC, power consumption 20 VA

Applications

The 8254200.9304.02449 with port G1/2 is used for washing and filling systems, gas lines and cooling circuits whenever gases and liquids have to be switched across 0 to 16 bar.

Standards and conformity

Documented for the Norgren 8254200.9304.02449: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254200.9304.02449 contains an SVHC substance and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8254200.9304.02449
Series82540
DesignForce-lifted diaphragm valve
Valve function2/2 NC (normally closed)
ActuationSolenoid pilot, spring return
Port sizeG1/2
Nominal diameter12 mm
Operating pressure0 to 16 bar
Kv value3.4 m³/h
Cv value3.9 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage24 V AC
Power consumption20 VA
Coil code9304
Protection classIP65
Vacuumdown to -0.9 bar
Country of originGermany
RoHScompliant
REACHcontains an SVHC substance
WEEEsubject to WEEE
Hersteller-Nr8254200.9304.02449
Zolltarifnummer84818059
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Nominal size DN [mm]12
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803
Betriebsdruck max [bar]16
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
