Diaphragm solenoid valve 2/2 NC, G 1/2, DN 12, 230 V AC, 82540 series - Norgren 8254200.4683.23049
The Norgren 8254200.4683.23049 switches gases and liquids through G 1/2 ports with DN 12 nominal size across 0 to 10 bar. The 4683 coil of the 8254200.4683.23049 runs on 230 V AC at 15.2 VA, protection class IP66 with cable gland, gland not supplied.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With Kv 3.4 m³/h at DN 12 and G 1/2 ports, the Norgren 8254200.4683.23049 switches gases and liquids across 0 to 10 bar. The 8254200.4683.23049 uses coil 4683 for 230 V AC at 15.2 VA with protection class IP66 with cable gland, gland not supplied. A brass body and NBR seals define the media compatibility of the 8254200.4683.23049.
Benefits
- Kv value 3.4 m³/h, Cv value 3.9 gpm at DN 12 nominal size
- Operating pressure 0 to 10 bar for gases and liquids
- Brass body, NBR seals
- Fluid temperature -10 to 90 °C, ambient temperature -10 to 50 °C
- Coil 4683 for 230 V AC, 15.2 VA, protection class IP66 with cable gland, gland not supplied
Applications
The 8254200.4683.23049 suits gases and liquids compatible with NBR, at fluid temperatures of -10 to 90 °C. As the operating pressure starts at 0 bar, the 8254200.4683.23049 switches without a minimum pressure difference.
Standards and compliance
The 8254200.4683.23049 uses a DIN EN 175301-803 form A electrical connection.
Technical data
| Product type | Diaphragm solenoid valve |
|---|---|
| Series | 82540 |
| Valve function | 2/2 |
| Function | NC (normally closed) |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1/2 |
| Nominal diameter | 12 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 3.4 m³/h |
| Cv flow coefficient | 3.9 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 15.2 VA |
| Coil code | 4683 |
| Protection class | IP66 with cable gland, gland not supplied |
| Manufacturer part number | 8254200.4683.23049 |
| Manufacturer | Norgren |
| Hersteller-Nr | 8254200.4683.23049 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/2 |
| Nominal size DN [mm] | 12 |
| Housing material | Brass |
| Design | diaphragm valve |
| Actuation type | Electrical |
| Medientemperatur [°C] | -10 bis 90 |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP66 |
