Force-lifted 2/2-way diaphragm valve NC, G1/2, DN 10, 110 V AC, EPDM - Norgren 8253214.8000.11050

Norgren ✓ Original product Brand new

The Norgren force-lifted diaphragm valve 8253214.8000.11050 switches gases and liquids at port G1/2 across 0 to 10 bar without differential pressure and reaches a Kv value of 1.7 m³/h. The solenoid coil 8000 for 110 V AC draws 20/16 VA, and EPDM seals handle media from -10 to 90 °C.

Net
€153.78
excl. VAT
Item NRG-8253214.8000.11050
Manufacturer no. 8253214.8000.11050
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With a Kv value of 1.7 m³/h and a nominal diameter of 10 mm the Norgren force-lifted diaphragm valve 8253214.8000.11050 controls lines with port G1/2, normally closed. Because the armature lifts the diaphragm positively, the 8253214.8000.11050 switches from 0 bar without differential pressure.

Operating benefits

  • Switches without differential pressure across 0 to 10 bar
  • Vacuum-rated down to -0.9 bar
  • Kv value 1.7 m³/h (Cv 1.97 gpm) at nominal diameter 10 mm
  • Compact solenoid system with integrated core tube
  • Seal material ethylene propylene diene rubber (EPDM) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 8000 for 110 V AC, power consumption 20/16 VA

Applications

Typical locations for the valve 8253214.8000.11050 are cooling circuits, washing and filling systems and gas lines where gases and liquids at temperatures of -10 to 90 °C have to be switched.

Standards and conformity

Documented for the Norgren 8253214.8000.11050: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8253214.8000.11050 contains no SVHC substances and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8253214.8000.11050
Series82530
DesignForce-lifted diaphragm valve
Valve function2/2 NC (normally closed)
ActuationSolenoid pilot, spring return
Port sizeG1/2
Nominal diameter10 mm
Operating pressure0 to 10 bar
Kv value1.7 m³/h
Cv value1.97 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialEthylene propylene diene rubber (EPDM)
Electrical connectionDIN EN 175301-803 form A
Operating voltage110 V AC
Power consumption20/16 VA
Coil code8000
Protection classIP65
Vacuumdown to -0.9 bar
Country of originGermany
RoHScompliant
REACHno SVHC substances
WEEEsubject to WEEE
Hersteller-Nr8253214.8000.11050
Zolltarifnummer84818059
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Nominal size DN [mm]10
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803
Betriebsdruck max [bar]10
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
