Force-lifted 2/2-way diaphragm valve NC, G1-1/4, DN 32, 230 V AC, FPM - Norgren 8254503.9404.23049
The Norgren force-lifted diaphragm valve 8254503.9404.23049 switches gases and liquids at port G1-1/4 across 0 to 16 bar without differential pressure and reaches a Kv value of 23 m³/h. The solenoid coil 9404 for 230 V AC draws 42 VA, and FPM seals handle media from -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a Kv value of 23 m³/h and a nominal diameter of 32 mm the Norgren force-lifted diaphragm valve 8254503.9404.23049 controls lines with port G1-1/4, normally closed. Because the armature lifts the diaphragm positively, the 8254503.9404.23049 switches from 0 bar without differential pressure.
Operating benefits
- Switches without differential pressure across 0 to 16 bar, suited to low or fluctuating pressure
- Vacuum-rated down to -0.9 bar
- Kv value 23 m³/h (Cv 26.6 gpm) at nominal diameter 32 mm
- Seal material fluoroelastomer (FPM) for fluid temperatures of -10 to 90 °C
- Solenoid coil 9404 for 230 V AC, power consumption 42 VA
Applications
Typical locations for the valve 8254503.9404.23049 are cooling circuits, washing and filling systems and gas lines where gases and liquids at temperatures of -10 to 90 °C have to be switched.
Standards and conformity
Documented for the Norgren 8254503.9404.23049: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254503.9404.23049 contains an SVHC substance and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8254503.9404.23049 |
| Series | 82540 |
| Design | Force-lifted diaphragm valve |
| Valve function | 2/2 NC (normally closed) |
| Actuation | Solenoid pilot, spring return |
| Port size | G1-1/4 |
| Nominal diameter | 32 mm |
| Operating pressure | 0 to 16 bar |
| Kv value | 23 m³/h |
| Cv value | 26.6 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Fluoroelastomer (FPM) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 42 VA |
| Coil code | 9404 |
| Protection class | IP65 |
| Vacuum | down to -0.9 bar |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains an SVHC substance |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8254503.9404.23049 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1-1/4 |
| Nominal size DN [mm] | 32 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
