Force-lifted 2/2-way diaphragm valve NC, G1-1/4, DN 32, 24 V DC, NBR - Norgren 8254502.9401.02400
The Norgren force-lifted diaphragm valve 8254502.9401.02400 switches gases and liquids at port G1-1/4 across 0 to 16 bar without differential pressure and reaches a Kv value of 23 m³/h. At port G1-1/4 the coil 9401 runs on 24 V DC, and NBR seals are rated for -10 to 90 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 8254502.9401.02400 is designed for gases and liquids across 0 to 16 bar with port G1-1/4 and nominal diameter 32 mm. Because the armature lifts the diaphragm positively, the 8254502.9401.02400 switches from 0 bar without differential pressure.
Operating benefits
- Switches without differential pressure across 0 to 16 bar, suited to low or fluctuating pressure
- Vacuum-rated down to -0.9 bar
- Kv value 23 m³/h (Cv 26.6 gpm) at nominal diameter 32 mm
- Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
- Solenoid coil 9401 for 24 V DC, power consumption 38 W
Applications
The 8254502.9401.02400 with port G1-1/4 is used for washing and filling systems, gas lines and cooling circuits whenever gases and liquids have to be switched across 0 to 16 bar.
Standards and conformity
Documented for the Norgren 8254502.9401.02400: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254502.9401.02400 contains an SVHC substance and falls under the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8254502.9401.02400 |
| Series | 82540 |
| Design | Force-lifted diaphragm valve |
| Valve function | 2/2 NC (normally closed) |
| Actuation | Solenoid pilot, spring return |
| Port size | G1-1/4 |
| Nominal diameter | 32 mm |
| Operating pressure | 0 to 16 bar |
| Kv value | 23 m³/h |
| Cv value | 26.6 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 24 V DC |
| Power consumption | 38 W |
| Coil code | 9401 |
| Protection class | IP65 |
| Vacuum | down to -0.9 bar |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | contains an SVHC substance |
| WEEE | subject to WEEE |
| Hersteller-Nr | 8254502.9401.02400 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1-1/4 |
| Nominal size DN [mm] | 32 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | Electrical |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
| Temperaturbereich | -10-90 °C |
| Temperature (max.) | 90 |
