Force-lifted 2/2-way diaphragm valve NC, G1-1/4, DN 32, 24 V DC, NBR - Norgren 8254500.9401.02400

Norgren ✓ Original product Brand new

The Norgren force-lifted diaphragm valve 8254500.9401.02400 switches gases and liquids at port G1-1/4 across 0 to 16 bar without differential pressure and reaches a Kv value of 23 m³/h. The solenoid coil 9401 for 24 V DC draws 38 W, and NBR seals handle media from -10 to 90 °C.

Net
€624.42
excl. VAT
Item NRG-8254500.9401.02400
Manufacturer no. 8254500.9401.02400
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren 8254500.9401.02400 is a normally closed force-lifted diaphragm valve of series 82540 for G1-1/4 lines with nominal diameter 32 mm. Forced lifting couples the diaphragm to the solenoid armature, so the G1-1/4 valve opens without differential pressure from 0 bar.

Operating benefits

  • Switches without differential pressure across 0 to 16 bar, suited to low or fluctuating pressure
  • Vacuum-rated down to -0.9 bar
  • Kv value 23 m³/h (Cv 26.6 gpm) at nominal diameter 32 mm
  • Seal material nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Solenoid coil 9401 for 24 V DC, power consumption 38 W

Applications

The Norgren 8254500.9401.02400 is installed in gas lines, cooling circuits and washing and filling systems where gases and liquids at 0 to 16 bar and ambient temperatures of -10 to 50 °C have to be controlled.

Standards and conformity

Documented for the Norgren 8254500.9401.02400: plug connection to DIN EN 175301-803 form A, protection class IP65 and RoHS compliance. Under REACH the valve 8254500.9401.02400 contains an SVHC substance and falls under the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part number8254500.9401.02400
Series82540
DesignForce-lifted diaphragm valve
Valve function2/2 NC (normally closed)
ActuationSolenoid pilot, spring return
Port sizeG1-1/4
Nominal diameter32 mm
Operating pressure0 to 16 bar
Kv value23 m³/h
Cv value26.6 gpm
MediumGases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialBrass
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage24 V DC
Power consumption38 W
Coil code9401
Protection classIP65
Vacuumdown to -0.9 bar
Weight5 kg
Country of originGermany
RoHScompliant
REACHcontains an SVHC substance
WEEEsubject to WEEE
Hersteller-Nr8254500.9401.02400
Zolltarifnummer84818059
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1-1/4
Nominal size DN [mm]32
Housing materialBrass
Function2/2 closed monostable
Actuation typeElectrical
NormDIN EN 175301-803
Betriebsdruck max [bar]16
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
