Solenoid actuated diaphragm valve with forced lifting, G1-1/2, 2/2 NC, 24 V AC - Norgren 8259600.9404.02449

The diaphragm valve with forced lifting Norgren 8259600.9404.02449 carries out function 2/2 NC with a Kv value of 25 m³/h.

Benefits

• High flow rate
• Damped operation
• For systems with low or fluctuating pressure
• Operating pressure 0 to 16 bar in function 2/2 NC
• Kv value 25 m³/h and Cv value 28.9 gpm
• Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C

Applications

Typical installations are cooling circuits, washing and filling plants and gas lines with fluid temperatures of -10 to 90 °C.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. The housing reaches protection class IP65.
