Diaphragm valve with forced lifting, 2/2 NC, G1-1/2, DN 40, NBR, 110 V DC - Norgren 8254601.8401.11000

Norgren ✓ Original product Brand new

Switches gases and liquids from 0 bar without differential pressure up to 10 bar, the Norgren diaphragm valve 8254601.8401.11000 reaches a Kv value of 25 m³/h at port G1-1/2. The 8254601.8401.11000 is normally closed, its coil 8401 runs on 110 V DC at 40 W with protection class IP65.

Net
€942.72
excl. VAT
Item NRG-8254601.8401.11000
Manufacturer no. 8254601.8401.11000
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren diaphragm valve 8254601.8401.11000 with forced lifting opens and closes port G1-1/2 at an operating pressure of 0 to 10 bar. At nominal diameter DN 40 the Kv value of the 8254601.8401.11000 is 25 m³/h, which also suits lines with low or fluctuating pressure.

Benefits

  • Kv value 25 m³/h or Cv value 28.9 gpm at port G1-1/2
  • Operates without differential pressure from 0 bar up to 10 bar
  • Seals made of nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C
  • Body made of brass for ambient temperatures of -10 to 50 °C
  • Coil 8401 with 110 V DC and 40 W, connection to DIN EN 175301-803 form A

Applications

The diaphragm valve 8254601.8401.11000 shuts off and opens lines carrying gases and liquids, for example in cooling circuits, washing and filling systems or compressed air distribution, provided NBR is compatible with the medium.

Standards and conformity

The 8254601.8401.11000 is RoHS compliant and contains an SVHC substance under REACH. The coil connector of the 8254601.8401.11000 follows DIN EN 175301-803 form A.

Technical data

ManufacturerNorgren
Part number8254601.8401.11000
Product typediaphragm valve
Series82540
Valve function2/2
Switching functionNC (normally closed)
Designdiaphragm valve with forced lifting
Valve technologydiaphragm
Port sizeG1-1/2
Nominal diameterDN 40
Operating pressure0 to 10 bar
Kv value25 m³/h
Cv value28.9 gpm
Mediumgases and liquids
Fluid temperature-10 to 90 °C
Ambient temperature-10 to 50 °C
Body materialbrass
Seal materialnitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A
Operating voltage110 V DC
Power consumption40 W
Coil code8401
Protection classIP65
Country of originGermany
RoHScompliant
REACHcontains SVHC substance
WEEEsubject to WEEE
Customs tariff number84818059
Hersteller-Nr8254601.8401.11000
Zolltarifnummer84818059
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Nominal size DN [mm]40
Housing materialBrass
Function2/2
Actuation typeElectrical
NormDIN EN 175301-803
Betriebsdruck max [bar]10
Pneumatic connectionG1 1/2
Protection ratingIP65
Temperaturbereich-10-90 °C
Temperature (max.)90
