Diaphragm solenoid valve 2/2 NC, G 1 1/2, DN 40, 110 V AC, 82540 series - Norgren 8254600.9404.11050
The Norgren 8254600.9404.11050 switches gases and liquids through G 1 1/2 ports with DN 40 nominal size across 0 to 16 bar. The 9404 coil of the 8254600.9404.11050 runs on 110 V AC at 42 VA, protection class IP65.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With Kv 25 m³/h at DN 40 and G 1 1/2 ports, the Norgren 8254600.9404.11050 switches gases and liquids across 0 to 16 bar. The 8254600.9404.11050 uses coil 9404 for 110 V AC at 42 VA with protection class IP65. A brass body and NBR seals define the media compatibility of the 8254600.9404.11050.
Benefits
- Kv value 25 m³/h, Cv value 28.9 gpm at DN 40 nominal size
- Operating pressure 0 to 16 bar for gases and liquids
- Brass body, NBR seals
- Fluid temperature -10 to 90 °C, ambient temperature -10 to 50 °C
- Coil 9404 for 110 V AC, 42 VA, protection class IP65
Applications
The 8254600.9404.11050 suits gases and liquids compatible with NBR, at fluid temperatures of -10 to 90 °C. As the operating pressure starts at 0 bar, the 8254600.9404.11050 switches without a minimum pressure difference.
Standards and compliance
The 8254600.9404.11050 uses a DIN EN 175301-803 form A electrical connection. The 8254600.9404.11050 is RoHS compliant, contains no SVHC substances under REACH and is covered by the WEEE directive.
Technical data
| Product type | Diaphragm solenoid valve |
|---|---|
| Series | 82540 |
| Valve function | 2/2 |
| Function | NC (normally closed) |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | G 1 1/2 |
| Nominal diameter | 40 mm |
| Operating pressure | 0 to 16 bar |
| Kv value | 25 m³/h |
| Cv flow coefficient | 28.9 gpm |
| Medium | Gases and liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 110 V AC |
| Power consumption | 42 VA |
| Coil code | 9404 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer part number | 8254600.9404.11050 |
| Manufacturer | Norgren |
| Hersteller-Nr | 8254600.9404.11050 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1 1/2 |
| Nominal size DN [mm] | 40 |
| Housing material | Brass |
| Design | diaphragm valve |
| Actuation type | Electrical |
| Medientemperatur [°C] | -10 bis 90 |
| Norm | DIN EN 175301-803 |
| Betriebsdruck max [bar] | 16 |
| Protection rating | IP65 |
