Direct solenoid actuated diaphragm valve with forced lifting, 3/4 NPS, 2/2, NC - Norgren 8264300.9154.23049
The actuator is separated from the medium and stays clean. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8264300.9154.23049 is designed for port 3/4 NPS and has a Kv value of 5.8 m³/h.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8264300.9154.23049 reaches protection class IP65 and seals with nitrile rubber (nbr).
Benefits
- The valve operates without differential pressure
- High flow rate
- Suitable for vacuum
- Port size 3/4 NPS
- Operating pressure 0 to 10 bar
- Body made of Brass
Applications
The valve is used in water treatment, cleaning and dosing plants and in gas lines.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8264300.9154.23049 |
| Series | 82640 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | 3/4 NPS |
| Nominal diameter | 20 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 5.8 m³/h |
| Cv flow coefficient | 6.7 gpm |
| Medium | Gases, Liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Brass |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 230 V AC |
| Power consumption | 20 VA |
| Coil code | 9154 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8264300.9154.23049 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
