Direct solenoid actuated diaphragm valve with forced lifting, 1/4 NPT, 2/2, NC - Norgren 8449000.3826.02400
Shuts off contaminated media reliably. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8449000.3826.02400 draws 13.6 W and reaches protection class NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 7, NEMA 9.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8449000.3826.02400 works at an operating pressure of 0 to 10 bar and is manufactured in Germany.
Benefits
- High flow rate
- Damped operation
- For systems with low or fluctuating pressure
- Port size 1/4 NPT
- Operating pressure 0 to 10 bar
- Body made of Stainless steel
Applications
The valve is used in water treatment, cleaning and dosing plants and in gas lines.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 7, NEMA 9.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8449000.3826.02400 |
| Series | 84490 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | 1/4 NPT |
| Nominal diameter | 5/16" |
| Operating pressure | 0 to 10 bar |
| Cv flow coefficient | 2.3 gpm |
| Medium | Gases, Liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 80 °C |
| Body material | Stainless steel |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | Flying leads |
| Operating voltage | 24 V DC |
| Power consumption | 13.6 W |
| Coil code | 3826 |
| Protection class | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 7, NEMA 9 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8449000.3826.02400 |
| Zolltarifnummer | 84818073 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
