Direct solenoid actuated diaphragm valve with forced lifting, 1/2 NPT, 2/2, NC - Norgren 8263203.8000.11000
The solenoid is replaced without tools. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8263203.8000.11000 has a Kv value of 1.7 m³/h and reaches protection class IP65.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Process valves switch water, gases and other media in process plants. The direct solenoid actuated diaphragm valve with forced lifting Norgren 8263203.8000.11000 runs on an operating voltage of 110 V DC and is designed for port 1/2 NPT.
Benefits
- Suitable for vacuum
- Compact solenoid with integrated core tube
- The valve operates without differential pressure
- Port size 1/2 NPT
- Operating pressure 0 to 10 bar
- Body made of Polyamide (PA)
Applications
The valve is used in water treatment, cleaning and dosing plants and in gas lines.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 8263203.8000.11000 |
| Series | 82630 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Diaphragm |
| Port size | 1/2 NPT |
| Nominal diameter | 10 mm |
| Operating pressure | 0 to 10 bar |
| Kv value | 1.7 m³/h |
| Cv flow coefficient | 1.97 gpm |
| Medium | Gases, Liquids |
| Fluid temperature | -10 to 90 °C |
| Ambient temperature | -10 to 50 °C |
| Body material | Polyamide (PA) |
| Seal material | Fluoropolymer (FPM) |
| Electrical connection | DIN EN 175301-803 form A |
| Operating voltage | 110 V DC |
| Power consumption | 12 W |
| Coil code | 8000 |
| Protection class | IP65 |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 8263203.8000.11000 |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
