Rotary indexing table, size 65, 8 index positions, 2.1 Nm, anticlockwise DHTG-65-8-A-L - Festo 8213368

With 2.1 Nm torque at 6 bar and 8 index positions, the DHTG-65-8-A-L forms the base for compact rotary transfer assembly systems. The axial runout of the plate is 0.02 mm.

Benefits

• 8 index positions: the plate indexes in steps of 45°
• Theoretical torque of 2.1 Nm at 6 bar
• Axial runout 0.02 mm, radial runout 0.02 mm, repetition accuracy 0.03°
• Static load capacity of 1000 N axial and 2000 N radial
• Operating pressure 3 to 8 bar
• Static tilting and tangential moments up to 100 Nm each

Applications

Workpiece holders are mounted on the plate of the DHTG-65-8-A-L and indexed station by station by the drive, for example for loading, screwing or marking. Centring sleeves locate the size 65 table on the machine frame.
