Pneumatic parallel gripper size 40, stroke per jaw 50 mm DHPL-40-100-P-A - Festo 8112225

Festo ✓ Original product Brand new

The parallel gripper DHPL-40-100-P-A holds prismatic and round parts and delivers 462 N gripping force per jaw when closing at 6 bar. 50 mm stroke per jaw, repetition accuracy 0.03 mm, double-acting, plain-bearing guide. Runs on 1.5 to 8 bar via G1/8 port. Position detection with proximity switches.

Net
€855.59
excl. VAT
Item FES-8112225
Manufacturer no. DHPL-40-100-P-A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The size 40 parallel gripper DHPL-40-100-P-A delivers 462 N gripping force per jaw when closing at 6 bar. Both jaws move parallel towards each other. Version DHPL-40-100-P-A: double-acting, plain-bearing guide, rack and pinion.

Benefits

  • 462 N gripping force per jaw when closing at 6 bar, total gripping force 924 N
  • Repetition accuracy 0.03 mm, replacement accuracy 0.2 mm
  • 50 mm stroke per jaw, with max. 801 g per external gripper finger
  • Closing time from 281 ms, opening time from 220 ms at 6 bar, operating frequency 1 Hz
  • Corrosion resistance class CRC 1, ambient temperature -10 to 60 °C

Applications

Typical tasks for the DHPL-40-100-P-A are assembly, feeding and pick-and-place in automated systems, at -10 to 60 °C ambient temperature. Gripper fingers are mounted on the jaws, each external finger may weigh up to 801 g. Position detection with proximity switches. Shipping weight 4.7 kg.

Technical data

Size40
Total stroke100 mm
Stroke per gripper jaw50 mm
Max. replacement accuracy0.2 mm
Max. angular gripper jaw backlash ax, ay0.1°
Max. gripper jaw backlash Sz0.065 mm
Rotational symmetry0.2 mm
Repetition accuracy, gripper0.03 mm
Number of gripper jaws2
Drive systemPneumatic
Mounting positionAny
Mode of operationDouble-acting
CushioningElastic cushioning rings/plates at both ends
Gripper functionParallel
Gripping force retentionNone
DesignRack and pinion
GuidePlain-bearing guide
Position detectionVia proximity switch
Operating pressure1.5 to 8 bar
Max. operating frequency of gripper1 Hz
Min. opening time at 6 bar220 ms
Min. closing time at 6 bar281 ms
Max. mass per external gripper finger801 g
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating mediumLubricated operation possible, after that always operate lubricated
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Degree of protectionIP54
Ambient temperature-10 to 60 °C
Total gripping force, opening at 6 bar1100 N
Total gripping force, closing at 6 bar924 N
Gripping force per gripper jaw, opening at 6 bar550 N
Gripping force per gripper jaw, closing at 6 bar462 N
Mass moment of inertia249.5 to 487.2 kgcm²
Max. force on gripper jaw Fz static750 N
Max. torque at gripper Mx static22 Nm
Max. torque at gripper My static22 Nm
Max. torque at gripper Mz static22 Nm
Maintenance intervalLifetime lubrication
Product weight4480 g
Type of mountingDirect mounting via thread, With through-hole
Pneumatic connectionG1/8
Note on materialsRoHS compliant
Cover cap materialWrought aluminium alloy, anodised
Cover materialAnodised wrought aluminium alloy
End plate materialAnodised wrought aluminium alloy
Housing materialAnodised wrought aluminium alloy
Gripper jaw materialAnodised wrought aluminium alloy
Piston seal materialTPE-U(PU)
Material piston rodHigh-alloy stainless steel
O-ring materialNBR
Screw materialGalvanised steel
Gear rack materialHigh-alloy stainless steel
Gear wheel materialSintered bronze
Weight4.7 kg
ManufacturerFesto
Hersteller-NrDHPL-40-100-P-A
EAN4052568573249
Zolltarifnummer84798997
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadG 1/8
MediumCompressed air
Functiondouble-acting
Actuation typepneumatic
Betriebsdruck max [bar]8
Protection ratingIP54
Temperaturbereich-10-60 °C
Temperature (max.)60
