Mini slide DGSL size 20 piston Ø 25 mm stroke 50 mm DGSL-20-50-C-Y3A - Festo 603831

Festo ✓ Original product Brand new

50 mm stroke in size 20: the DGSL-20-50-C-Y3A is a mini slide from the Festo DGSL series with a 25 mm piston. End position cushioning is provided by progressive shock absorbers at both ends. Compressed air is connected via G1/8. Weight 2.3 kg.

Net
€1,105.25
excl. VAT
Item FES-603831
Manufacturer no. DGSL-20-50-C-Y3A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

50 mm stroke, piston Ø 25 mm, port G1/8: these are the key data of the Festo mini slide DGSL-20-50-C-Y3A from the DGSL series.

Benefits

  • Pneumatic connection G1/8
  • Stroke 50 mm in size 20
  • Piston diameter 25 mm
  • Weight 2.3 kg
  • Cushioning Y3: Shock absorbers, progressive, at both ends

Applications

DGSL series mini slides are used as lifting and transverse axes in handling and assembly. Check forces, torques and the type segments of the DGSL-20-50-C-Y3A in the Festo datasheet before use.

Technical data

TypeDGSL-20-50-C-Y3A
SeriesFesto DGSL
Size20
Stroke50 mm
Piston diameter25 mm
CushioningY3: Shock absorbers, progressive, at both ends
Pneumatic connectionG1/8
Weight2.3 kg
Festo part number603831
HS code84123100
ManufacturerFesto
Hersteller-NrDGSL-20-50-C-Y3A
Zolltarifnummer84123100
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Piston Ø [mm]25
Stroke [mm]50
MediumCompressed air
Bore (mm)25
