Mini slide DGSL size 20 piston Ø 25 mm stroke 30 mm DGSL-20-30-C-Y3A - Festo 593508

Festo ✓ Original product Brand new

The Festo mini slide DGSL-20-30-C-Y3A from the DGSL series travels a 30 mm stroke with a 25 mm piston. End position cushioning is provided by progressive shock absorbers at both ends. Compressed air is connected via G1/8. Weight 2.1 kg.

Net
€1,042.00
excl. VAT
Item FES-593508
Manufacturer no. DGSL-20-30-C-Y3A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The mini slide DGSL-20-30-C-Y3A belongs to the Festo DGSL series in size 20. It offers a 30 mm stroke with a 25 mm piston diameter.

Benefits

  • Stroke 30 mm in size 20
  • Pneumatic connection G1/8
  • Cushioning Y3: Shock absorbers, progressive, at both ends
  • Weight 2.1 kg
  • Piston diameter 25 mm

Applications

DGSL series mini slides are used as lifting and transverse axes in handling and assembly. Check forces, torques and the type segments of the DGSL-20-30-C-Y3A in the Festo datasheet before use.

Technical data

TypeDGSL-20-30-C-Y3A
SeriesFesto DGSL
Size20
Stroke30 mm
Piston diameter25 mm
CushioningY3: Shock absorbers, progressive, at both ends
Pneumatic connectionG1/8
Weight2.1 kg
Festo part number593508
HS code84123100
ManufacturerFesto
Hersteller-NrDGSL-20-30-C-Y3A
Zolltarifnummer84123100
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Piston Ø [mm]25
Stroke [mm]30
MediumCompressed air
Bore (mm)25
