Mini slide DGSL size 20 piston Ø 25 mm stroke 100 mm DGSL-20-100-C-Y3A - Festo 593506

Festo ✓ Original product Brand new

As a mini slide from the Festo DGSL series in size 20, the DGSL-20-100-C-Y3A offers a 100 mm stroke. End position cushioning is provided by progressive shock absorbers at both ends. Compressed air is connected via G1/8. Weight 3.3 kg.

Net
€1,263.38
excl. VAT
Item FES-593506
Manufacturer no. DGSL-20-100-C-Y3A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

100 mm stroke, piston Ø 25 mm, port G1/8: these are the key data of the Festo mini slide DGSL-20-100-C-Y3A from the DGSL series.

Benefits

  • Pneumatic connection G1/8
  • Cushioning Y3: Shock absorbers, progressive, at both ends
  • Stroke 100 mm in size 20
  • Piston diameter 25 mm
  • Weight 3.3 kg

Applications

DGSL series mini slides are used as lifting and transverse axes in handling and assembly. Check forces, torques and the type segments of the DGSL-20-100-C-Y3A in the Festo datasheet before use.

Technical data

TypeDGSL-20-100-C-Y3A
SeriesFesto DGSL
Size20
Stroke100 mm
Piston diameter25 mm
CushioningY3: Shock absorbers, progressive, at both ends
Pneumatic connectionG1/8
Weight3.3 kg
Festo part number593506
HS code84123100
ManufacturerFesto
Hersteller-NrDGSL-20-100-C-Y3A
Zolltarifnummer84123100
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Piston Ø [mm]25
Stroke [mm]100
MediumCompressed air
Bore (mm)25
