Mini slide DGSL size 20 piston Ø 25 mm stroke 10 mm DGSL-20-10-C-EA - Festo 609267

Festo ✓ Original product Brand new

As a mini slide from the Festo DGSL series in size 20, the DGSL-20-10-C-EA offers a 10 mm stroke. End position cushioning is provided by short flexible cushioning rings at both ends. Compressed air is connected via G1/8. Weight 1.9 kg.

Net
€742.46
excl. VAT
Item FES-609267
Manufacturer no. DGSL-20-10-C-EA
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

10 mm stroke, piston Ø 25 mm, port G1/8: these are the key data of the Festo mini slide DGSL-20-10-C-EA from the DGSL series.

Benefits

  • Weight 1.9 kg
  • Stroke 10 mm in size 20
  • Piston diameter 25 mm
  • Cushioning Short flexible cushioning rings/pads at both ends
  • Pneumatic connection G1/8

Applications

The DGSL-20-10-C-EA suits feeding, assembly and pick-and-place tasks with 10 mm travel. Please take the load limits from the Festo datasheet for the full type.

Technical data

TypeDGSL-20-10-C-EA
SeriesFesto DGSL
Size20
Stroke10 mm
Piston diameter25 mm
CushioningShort flexible cushioning rings/pads at both ends
Pneumatic connectionG1/8
Weight1.9 kg
Festo part number609267
HS code84123100
ManufacturerFesto
Hersteller-NrDGSL-20-10-C-EA
Zolltarifnummer84123100
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Piston Ø [mm]25
Stroke [mm]10
MediumCompressed air
Bore (mm)25
