Mini slide DGSL size 16 piston Ø 20 mm stroke 100 mm DGSL-16-100-C-Y3A - Festo 593501
The Festo mini slide DGSL-16-100-C-Y3A from the DGSL series travels a 100 mm stroke with a 20 mm piston. End position cushioning is provided by progressive shock absorbers at both ends. Compressed air is connected via M5. Weight 1.9 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The mini slide DGSL-16-100-C-Y3A belongs to the Festo DGSL series in size 16. It offers a 100 mm stroke with a 20 mm piston diameter.
Benefits
- Piston diameter 20 mm
- Pneumatic connection M5
- Weight 1.9 kg
- Stroke 100 mm in size 16
- Cushioning Y3: Shock absorbers, progressive, at both ends
Applications
The DGSL-16-100-C-Y3A suits feeding, assembly and pick-and-place tasks with 100 mm travel. Please take the load limits from the Festo datasheet for the full type.
Technical data
| Type | DGSL-16-100-C-Y3A |
|---|---|
| Series | Festo DGSL |
| Size | 16 |
| Stroke | 100 mm |
| Piston diameter | 20 mm |
| Cushioning | Y3: Shock absorbers, progressive, at both ends |
| Pneumatic connection | M5 |
| Weight | 1.9 kg |
| Festo part number | 593501 |
| HS code | 84123100 |
| Manufacturer | Festo |
| Hersteller-Nr | DGSL-16-100-C-Y3A |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | M5 |
| Piston Ø [mm] | 20 |
| Stroke [mm] | 100 |
| Medium | Compressed air |
| Bore (mm) | 20 |
