Mini slide DGSL size 12 piston Ø 16 mm stroke 50 mm DGSL-12-50-C-P1A - Festo 593499
The Festo mini slide DGSL-12-50-C-P1A from the DGSL series travels a 50 mm stroke with a 16 mm piston. End position cushioning is provided by flexible cushioning rings with a fixed stop. Compressed air is connected via M5. Weight 0.9 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The mini slide DGSL-12-50-C-P1A belongs to the Festo DGSL series in size 12. It offers a 50 mm stroke with a 16 mm piston diameter.
Benefits
- Pneumatic connection M5
- Stroke 50 mm in size 12
- Weight 0.9 kg
- Cushioning P1: Flexible cushioning rings/pads at both ends with fixed stop
- Piston diameter 16 mm
Applications
DGSL series mini slides are used as lifting and transverse axes in handling and assembly. Check forces, torques and the type segments of the DGSL-12-50-C-P1A in the Festo datasheet before use.
Technical data
| Type | DGSL-12-50-C-P1A |
|---|---|
| Series | Festo DGSL |
| Size | 12 |
| Stroke | 50 mm |
| Piston diameter | 16 mm |
| Cushioning | P1: Flexible cushioning rings/pads at both ends with fixed stop |
| Pneumatic connection | M5 |
| Weight | 0.9 kg |
| Festo part number | 593499 |
| HS code | 84123100 |
| Manufacturer | Festo |
| Hersteller-Nr | DGSL-12-50-C-P1A |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | M5 |
| Piston Ø [mm] | 16 |
| Stroke [mm] | 50 |
| Medium | Compressed air |
| Bore (mm) | 16 |
