Stopperzylinder DFSP-Q-16-15-PF-PA - Festo 588707

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Stopper cylinder, non-rotating, single-acting pulling, Ø 16 mm, stroke 15 mm DFSP-Q-16-15-PF-PA - Festo 588707

Name: Stopper cylinder, non-rotating, single-acting pulling, Ø 16 mm, stroke 15 mm DFSP-Q-16-15-PF-PA - Festo 588707
Brand: Festo
SKU: FES-588707
Price: 104.64 EUR
Availability: InStock

Festo ✓ Original product Brand new

Non-rotating DFSP-Q stopper cylinder with 16 mm piston diameter and 15 mm stroke for stopping workpiece carriers. Single-acting, pulling: compressed air retracts the piston rod and a spring returns it.

Net

€104.64

excl. VAT

Item FES-588707

Manufacturer no. DFSP-Q-16-15-PF-PA

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DFSP-Q-16-15-PF-PA belongs to the non-rotating DFSP-Q series and stops workpiece carriers with 16 mm piston diameter and 15 mm stroke. Impact force, lateral force and operating pressure of this version are given in the Festo data sheet for part number 588707.

Benefits

Piston diameter 16 mm and stroke 15 mm
Non-rotating thanks to a flattened piston rod
Single-acting, pulling with spring return, piston rod end with female thread

Technical data

Order code	DFSP-Q-16-15-PF-PA
Festo part number	588707
Series	DFSP-Q
Piston diameter	16 mm
Stroke	15 mm
Mode of operation	single-acting, pulling
Protection against torque/guide	flattened piston rod
Piston rod end	female thread
Weight according to price list	0.15 kg
Weight	0.15 kg
Manufacturer	Festo
Hersteller-Nr	DFSP-Q-16-15-PF-PA
Zolltarifnummer	84123100
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
Piston Ø [mm]	16
Stroke [mm]	15
Function	single-acting
Actuation type	pneumatic
Bore (mm)	16
