Piston drive DFPK-46-17-D-V4 - Festo 8083962

Name: Piston drive DFPK-46-17-D-V4 - Festo 8083962
Brand: Festo
SKU: FES-8083962
Price: 266.77 EUR
Availability: InStock

Festo ✓ Original product Brand new

Net

€266.77

excl. VAT

Item FES-8083962

Manufacturer no. DFPK-46-17-D-V4

Datasheet (PDF)

Technical data

Size of valve actuator	46
Stroke	17 mm
Mounting position	Any
Position detection	Via mechanical indicator
Control function	Double-acting
Operating pressure	5 ... 10 bar
CE mark (see declaration of conformity)	To EU Explosion Protection Directive (ATEX)
UKCA marking (see declaration of conformity)	To UK EX instructions
Explosion protection certification outside the EU	EPL Gb (GB)
Explosion protection	Zone 1 (ATEX), Zone 1 (UKEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 21 (UKEX), Zone 22 (ATEX)
ATEX category gas	II 2G
ATEX category dust	II 2D
Explosion ignition protection type for gas	Ex h IIC T6...T4 Gb
Explosion ignition protection type for dust	Ex h IIIC T80°C...T120°C Db
Explosion ambient temperature	0°C <= Ta <= +60°C
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
LABS (PWIS) conformity	VDMA24364 zone III
Storage temperature	-10 ... 60 °C
Degree of protection	IP65, IP67, IP69K
Ambient temperature	0 ... 60 °C
Product weight	1210 g
Pneumatic connection	Female thread G1/8
Note on materials	RoHS compliant
Material cover	Cast stainless steel
Material seals	Fluoro rubber
Material housing	Cast stainless steel
Material number housing	1,4408
Material piston rod	High-alloy stainless steel
Manufacturer	Festo
Hersteller-Nr	DFPK-46-17-D-V4
EAN	4052568457778
Zolltarifnummer	84123100
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
