Reducing sleeve SW36 to SW22, length 36 mm DARQ-R-A-S36-S22-36 - Festo 8096915
The reducing sleeve DARQ-R-A-S36-S22-36 links a drive outlet to a smaller width across flats. SW36 on the drive side meets SW22 on the reducing side. Material: sintered steel, stainless. Corrosion class: CRC 2 (moderate corrosion stress). Product weight 286 g. Note on materials: RoHS compliant.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The reducing sleeve DARQ-R-A-S36-S22-36 links a drive outlet to a smaller width across flats. SW36 on the drive side meets SW22 on the reducing side. Material: sintered steel, stainless.
At a glance
- Drive outlet SW36, reducing outlet SW22
- Material sleeve: sintered steel, stainless
- Corrosion resistance class CRC 2 - moderate corrosion stress
- LABS (PWIS) conformity VDMA24364 zone III
Application
The DARQ-R-A-S36-S22-36 is used when mounting quarter-turn actuators on process valves such as ball valves and butterfly valves.
Technical data
| Order type | DARQ-R-A-S36-S22-36 |
|---|---|
| Festo part number | 8096915 |
| Length | 36 mm |
| Size of pack | 1 |
| Design | square socket and octagon drive, reducing sleeve |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Product weight | 286 g |
| Connection 1, function | drive outlet |
| Connection 1, design | SW36 |
| Connection 2, function | reducing outlet |
| Connection 2, design | SW22 |
| Note on materials | RoHS compliant |
| Material sleeve | sintered steel, stainless |
| Customs tariff number | 73269098 |
| Weight | 0.24 kg |
| Manufacturer | Festo |
| Hersteller-Nr | DARQ-R-A-S36-S22-36 |
| EAN | 4052568451981 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | DARQ |
