Montagebrücke DARQ-B-F30-F16-R13 - Festo 8083001
Montagebrücke DARQ-B-F30-F16-R13 - Festo 8083001 Montagebrücke DARQ-B-F30-F16-R13 - Festo 8083001

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Mounting bridge in galvanised steel DARQ-B-F30-F16-R13 - Festo 8083001

Festo ✓ Original product Brand new

The mounting bridge DARQ-B-F30-F16-R13 belongs to the Festo DARQ range for mounting quarter-turn actuators on valves. Bohrbild 30 on the drive side meets Bohrbild 16 on the reducing side. Material mounting bridge according to Festo: galvanised steel. Product weight 16740 g.

Net
€970.88
excl. VAT
Item FES-8083001
Manufacturer no. DARQ-B-F30-F16-R13
Save Compare
Question about this item
Datasheet (PDF)
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The mounting bridge DARQ-B-F30-F16-R13 belongs to the Festo DARQ range for mounting quarter-turn actuators on valves. Bohrbild 30 on the drive side meets Bohrbild 16 on the reducing side. Material mounting bridge according to Festo: galvanised steel.

At a glance

  • Drive outlet Bohrbild 30, reducing outlet Bohrbild 16
  • Material mounting bridge: galvanised steel
  • Corrosion resistance class CRC 2 - moderate corrosion stress
  • LABS (PWIS) conformity VDMA24364 zone III

Typical applications

Its field is process automation: the DARQ-B-F30-F16-R13 links quarter-turn actuator and valve, for instance on ball and butterfly valves.

Technical data

Order typeDARQ-B-F30-F16-R13
Festo part number8083001
Size of pack1
Designmounting bridge
Corrosion resistance class CRC2 - moderate corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Product weight16740 g
Connection 1, functiondrive outlet
Connection 1, designport pattern 30
Connection 2, functionreducing outlet
Connection 2, designport pattern 16
Note on materialsRoHS compliant
Material mounting bridgegalvanised steel
Customs tariff number73269098
Weight16 kg
ManufacturerFesto
Hersteller-NrDARQ-B-F30-F16-R13
EAN4052568448455
Zolltarifnummer73269098
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialGalvanised steel
SeriesDARQ
