Sub-base kit for mounting on the drive, size 6, up to 60 N DADP-SP-G9-6-R - Festo 8173532
The DADP-SP-G9-6-R sub-base kit creates the mounting interface for add-on parts on the drive. Key data: size 6, stop force up to 60 N, mounting: direct mounting via thread and ambient temperature -10 to 60 °C. It is used when building stop and cushioning solutions on compact drives.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The DADP-SP-G9-6-R sub-base kit creates the mounting interface for add-on parts on the drive. Decisive for selection: size 6 and stop force up to 60 N.
Benefits
- Withstands stop forces up to 60 N
- Ambient temperature -10 to 60 °C
- Cleanroom-compatible, class 6 to ISO 14644-1
- Suitable for battery production with reduced Cu/Zn/Ni content (F1a)
- PWIS conformity VDMA24364-C1-L
- CRC 2: designed for moderate corrosion stress
Application
It is used when building stop and cushioning solutions on compact drives.
Technical data
| Type | DADP-SP-G9-6-R |
|---|---|
| Festo part number | 8173532 |
| Size | 6 |
| Mounting position | any |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| PWIS conformity | VDMA24364-C1-L |
| Suitability for the production of Li-ion batteries | suitable for battery production with reduced Cu/Zn/Ni content (F1a) |
| Cleanroom suitability, measured to ISO 14644-14 | class 6 to ISO 14644-1 |
| Ambient temperature | -10 to 60 °C |
| Max. stop force | 60 N |
| Max. tightening torque | 0.3 Nm |
| Tightening torque tolerance | ± 15 % |
| Product weight | 24 g |
| Mounting type | direct mounting via thread |
| Note on materials | RoHS-compliant |
| Stop material | high-alloy steel |
| Seal material | NBR |
| Plate material | wrought aluminium alloy, anodised |
| Screw material | steel |
| Manufacturer | Festo |
| Hersteller-Nr | DADP-SP-G9-6-R |
| EAN | 4052568631130 |
| Zolltarifnummer | 76169990 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | DADP |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
