Stop kit for end position adjustment, size 6, up to 60 N DADP-SP-G9-6-F - Festo 8173536

Festo ✓ Original product Brand new

The DADP-SP-G9-6-F stop kit limits the range of motion and makes the end position adjustable. Main data: size 6, stop force up to 60 N, mounting: direct mounting via thread and ambient temperature -10 to 60 °C. It is retrofitted when end positions need to be adapted to the system or fine-tuned.

Net
€22.29
excl. VAT
Item FES-8173536
Manufacturer no. DADP-SP-G9-6-F
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The DADP-SP-G9-6-F stop kit limits the range of motion and makes the end position adjustable. At a glance: size 6 and stop force up to 60 N.

Benefits

  • Withstands stop forces up to 60 N
  • Ambient temperature -10 to 60 °C
  • Cleanroom-compatible, class 6 to ISO 14644-1
  • Suitable for battery production with reduced Cu/Zn/Ni content (F1a)
  • PWIS conformity VDMA24364-C1-L
  • CRC 2: designed for moderate corrosion stress

Application

It is retrofitted when end positions need to be adapted to the system or fine-tuned.

Technical data

TypeDADP-SP-G9-6-F
Festo part number8173536
Size6
Mounting positionany
Corrosion resistance class CRC2 - moderate corrosion stress
PWIS conformityVDMA24364-C1-L
Suitability for the production of Li-ion batteriessuitable for battery production with reduced Cu/Zn/Ni content (F1a)
Cleanroom suitability, measured to ISO 14644-14class 6 to ISO 14644-1
Ambient temperature-10 to 60 °C
Max. stop force60 N
Max. tightening torque0.4 Nm
Tightening torque tolerance± 15 %
Product weight12 g
Mounting typedirect mounting via thread
Note on materialsRoHS-compliant
Stop materialhigh-alloy steel
Screw materialsteel
ManufacturerFesto
Hersteller-NrDADP-SP-G9-6-F
EAN4052568631154
Zolltarifnummer84129070
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesDADP
Temperaturbereich-10-60 °C
Temperature (max.)60

Downloads

Questions about this item

Any other question?

Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
